GENERAL
UPS Topology
| Line-interactive |
INPUT
Generator Compatibility
| Yes |
Nominal Input Voltage (Vac)
| 230 ± 10% |
Input Voltage Range (Vac)
| 170 ~ 290 |
Input Frequency (Hz)
| 50 ± 5 |
| 60 ± 5 |
Input Frequency Detection
| Auto-sensing |
Rated Input Current (A)
| 2.95 |
Input Connector Type
| AU | |
OUTPUT
Capacity (VA)
| 650 |
Capacity (Watts)
| 390 |
On Battery Waveform
| Simulated Sine Wave |
On Battery Voltage(s) (Vac)
| 230 ± 10% |
On Battery Frequency (Hz)
| 50 ± 1% |
| 60 ± 1% |
Automatic Voltage Regulation (AVR)
| Single Boost, Single Buck |
Overload Protection
| Fuse |
Outlet(s) - Total
| 3 |
Outlet Type
| AU x 3 | |
Outlet(s) - Battery & Surge Protected
| 3 |
Typical Transfer Time (ms)
| 4 |
BATTERY
Runtime at 60W (min)
| 35 |
Runtime at 90W (min)
| 21 |
Typical Recharge Time (Hours)
| 8 |
Start On Battery
| Yes |
User-replaceable
| No |
Battery Type
| Sealed Lead-acid |
SURGE PROTECTION & FILTERING
Surge Suppression (Joules)
| 125 |
EMI/RFI Filtration
| Yes |
MANAGEMENT & COMMUNICATIONS
LED Indicators
| Power On , Line Mode , Battery Mode , Low Battery |
Audible Alarms
| Battery Mode , Low Battery , Overload , UPS Fault |
PHYSICAL
Form Factor
| Brick |
Enclosure Construction
| Plastic |
Color
| Black |
PHYSICAL SIZE - UPS MODULE
Dimensions (WxHxD) (in.)
| 6.33 x 3.6 x 9.45 |
Dimensions (WxHxD) (mm.)
| 158 x 91.5 x 240 |
Weight (lbs.)
| 9.04 |
Weight (kg.)
| 4.1 |
ENVIRONMENTAL
Operating Temperature (°F)
| 32 ~ 104 |
Operating Temperature (°C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing) (%)
| 0 ~ 90 |
Operating Elevation (feet/meters)
| 0-10,000 feet (0-3,000 meters) |
Storage Temperature (°F)
| -4 ~ 122 |
Storage Temperature (°C)
| -20 ~ 50 |
Storage Relative Humidity (Non-condensing) (%)
| 0 ~ 90 |
Storage Elevation (feet/meters)
| 0-10,000 feet (0-3,000 meters) |
Online Thermal Dissipation (BTU/hr)
| 40 |
Audible Noise at 1.5M from Surface of Unit (dBA)
| 40 |
CERTIFICATIONS
Certifications
| CE , RCM |
RoHS
| Yes |
WARRANTY
Product Warranty Period (Year)2
Battery Warranty Period (Year)
