Leírás és Paraméterek
|
Type |
Managed |
|---|---|
|
Number of ports |
16 to 30 ports |
|
Layer |
Layer 3 |
|
Stacking |
Physical Virtual |
|
Main type of ports |
2.5GBASE-T Ethernet 5GBASE-T Ethernet |
|
Type of uplink ports |
10GBASE-T 25GbE SFP28 |
|
Switching capacity |
360 Gbps 400 Gbps |
|
PoE options |
802.3af 802.3at 802.3bt draft |
|
Number of PoE ports |
24 |
|
PoE power budget |
740W 960W with DPS-PWR740AC |
|
D-Link Green |
|
|
802.3az Energy-Efficient Ethernet support |
|
|
Form Factor |
Rackmountable |
|
Housing |
Metal |
|
Physical stacking |
Up to 9 devices |
|
Virtual stacking (up to 32 devices) |
|
|
Jumbo frame |
|
|
MAC address |
32K |
|
Spanning Tree Protocol |
802.1D STP 802.1s MSTP 802.1w RSTP |
|
Ethernet ring protection switching (ERPS) |
|
|
Link aggregation |
802.1AX 802.3ad |
|
VLAN group (max static) |
4K |
|
VLAN type |
GVRP MAC-based Port-based Protocol-based |
|
Advanced VLAN |
Asymmetric VLAN Auto Surveillance VLAN Double VLAN (Q-in-Q) ISM VLAN Super VLAN Voice VLAN |
|
IPv4/IPv6 routing table |
IPv4 - 1K IPv6 - 512 |
|
IPv4/IPv6 forwarding table |
IPv4 - 4K IPv6 - 2K |
|
IP interfaces |
128 |
|
Static route for IPv4/IPv6 |
IPv4 - 512 IPv6 - 256 |
|
Multicasting |
|
|
PIM-SM |
|
|
RIP v1/v2 |
|
|
RIPng |
|
|
OSPF |
|
|
OSPFv3 |
|
|
Number of QoS queues per port |
8 |
|
CoS based on contents |
|
|
Bandwidth control |
8 Kbps minimum granularity |
|
Port-based QoS |
|
|
Three colour marker |
8 Kbps minimum granularity |
|
ACL type |
Egress Ingress VLAN-based |
|
ACL based on packet contents |
|
|
Time-based ACL |
|
|
Encryption protocol supported |
SSH SSL (v1/v2/v3) |
|
IP-MAC-port binding (IMPB) / Smart Binding |
|
|
ARP spoofing |
|
|
BPDU attack protection |
|
|
802.1X access control |
|
|
RADIUS/TACACS+ authentication |
|
|
SNMP (v1/v2c/v3) |
|
|
RMON v1/v2 |
|
|
sFlow |
|
|
LLDP |
|
|
LLDP-MED |
|
|
ICMPv6 |
|
|
802.3ah |
|
|
802.1ag |
|
|
ITU-T Y.1731 |
