Leírás és Paraméterek
-
3.5" or 2.5" drive capacity
2
-
Dedicated 2.5" drive capacity
3 (maximum 2.5" drive thickness is 10 mm)
-
Expansion slots
7
-
Front ports
2x USB 3.0, Audio in/out, Power button with LED, HDD activity LED, Reset button
-
Total fan mounts
7
-
Front fan
3x 120 or 2x 140 mm (1 x Dynamic X2 GP-12 included)
-
Top fan
2x 120/140 mm
-
Rear fan
1x 120 mm (1 x Dynamic X2 GP-12 included)
-
Bottom fan
1x 120 mm
-
Dust filters
Bottom fan + PSU, Front fans, Top fans (optional)
-
Cable routing grommets
Yes
-
Fixed Velcro straps
Yes
-
Captive thumbscrews
Right side panel, SSD brackets
-
Left side panel
Industrial sound-dampened steel
-
Right side panel
Industrial sound-dampened steel
Compatibility
-
Power supply type
ATX
-
Motherboard compatibility
ATX, mATX, ITX
-
Front radiator
120/240/360 mm or 140/280 mm (max 144 mm width)
-
Top radiator
120/240 mm (max 40 mm motherboard component height)
-
Rear radiator
120 mm (max 125 mm width)
-
PSU max length
175 mm
-
GPU max length
Max 315 mm with front fan mounted
-
CPU cooler max height
172 mm
-
Cable routing space
15-35 mm
Dimensions
-
Case dimensions (LxWxH)
399 x 210 x 440 mm
-
Case dimensions - with feet/protrusions/screws
413 x 210 x 453 mm
-
Net weight
7.4 kg
-
Package dimensions (LxWxH)
542 x 305 x 493 mm
-
Package weight
7.81 kg
-
Volume
36.9 liters
