Leírás és Paraméterek
-
Dedicated 2.5" drive mounts
2
-
Combined 3.5/2.5” drive mounts
2 (included)
-
5.25” drive mounts
0
-
Expansion slots
7
-
Front interface
1xUSB 3.1 Gen 2 Type-C, 2xUSB 3.0, Audio & Mic
-
Total fan mounts
8 x 120 mm or 6 x 140 mm
-
Front fan
3 x 120, 2 x 140 mm (2 x Aspect 140 mm PWM Included)
-
Top Fan
2 x 120/140 mm
-
Rear fan
1 x 120 mm
-
Dust filters
Front, PSU
-
Fixed cable straps
Yes
-
Cable routing grommets
Yes
-
Captive thumbscrews
HDD brackets, SSD bracket, Side Panels, Fan Bracket, PSU Bracket
-
Left side panel
Mesh or tempered glass
-
Right side panel
Steel
Compatibility
-
Motherboard compatibility
ATX / mATX / Mini-ITX
-
Power supply type
ATX
-
PSU max length
1 HDD Tray: 255 mm max, 2 HDD Tray: 155 mm max
-
GPU max length
355 mm with and without front fan mounted
-
CPU cooler max height
145 mm with Fan Bracket (Mesh version only)/ 170 mm w.o
-
Front radiator
Up to 360 mm
-
Top radiator
Up to 240 mm (See manual for details on ram clearance)
-
Rear radiator
1 x 120 mm (If using a rear radiator the mesh version fan bracket can only be slotted into the bottom position)
-
Cable routing space
30 mm
Dimensions
-
Case dimensions (LxWxH)
447 x 215 x 469 mm
-
Case dimensions w/o feet/protrusions/screws
433,5 x 215 x 450 mm
-
Net weight
7.6 kg (Mesh) / 7.7kg (TG)
-
Package dimensions (LxWxH)
565 x 326 x 553 mm
-
Gross weight
9.55 kg (Mesh) / 9.3kg (TG)
