Leírás és Paraméterek
-
3.5"/2.5" drive mounts
1 (included)
-
Dedicated 2.5" drive mounts
3 (included)
-
Expansion slots
7
-
Front interface
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio
-
Total fan mounts
2x 180 mm, 4x 140 mm, or 6x 120 mm (with included brackets)
-
Front fan
2x 180, 2x 140 mm, or 3x 120 mm (with included brackets) (2x Dynamic GP-18 included in standard versions, 2x Prisma AL-18 included in RGB version)
-
Dust filters
Front, Bottom
-
Fixed cable straps
Yes
-
Cable routing grommets
Yes
-
Tool-less push-to-lock
Side panels
-
Captive thumbscrews
HDD and SSD brackets
-
Left side panel
Steel or Tempered glass (RGB version: Tempered glass only)
-
Right side panel
Steel or Tempered glass (Solid/White RGB: Steel, TG/Black RGB: Tempered Glass)
Compatibility
-
Motherboard compatibility
E-ATX (up to 274 mm) / ATX / mATX / Mini-ITX / SSI-CEB
-
Power supply type
ATX
-
PSU max length
210 mm
-
GPU max length
330 mm with front fan mounted
-
CPU cooler max height
174 mm
-
Rear fan
1x 120 mm (not included)
-
Bottom fan
2x 180 mm (with mATX motherboard), 2x 140 mm, or 3x 120 mm
-
Front radiator
Up to 360x120/280x140 mm (360 mm front radiators (push / push-pull) supported up to a max length of 403 mm)
-
Rear radiator
120x120 mm
-
Bottom radiator
Up to 240x120/280x140 mm
-
Cable routing space
20 mm
Dimensions
-
Case dimensions (LxWxH)
450 x 222 x 467 mm
-
Net weight
BK TGD/TGL: 8.0 kg, WT TGC: 7.7 kg, BK Solid: 7.4 kg
-
Package dimensions (LxWxH)
535 x 306 x 574 mm
-
Gross weight
BK TGD/TGL: 9.7 kg, WT TGC: 9.5 kg, BK Solid: 9.2 kg
