Leírás és Paraméterek
-
Dedicated 3.5" drive mounts
2 (included)
-
Dedicated 2.5" drive mounts
4 (included)
-
Expansion slots
7
-
Front interface
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, HD Audio
-
Total fan mounts
7x 120/140 mm or 4x 180 mm
-
Front fan
3x 120/140 mm or 2x 180 mm (2x Dynamic GP-18 included in standard version, 2x Prisma AL-18 included in RGB version)
-
Rear fan
1x 120/140 mm
-
Bottom fan
3x 120/140 mm or 2x 180 mm (3x Dynamic GP-14 PWM included in standard version, 3x Prisma AL-14 PWM included in RGB version)
-
Dust filters
Front, Bottom
-
Fixed cable straps
Yes
-
Cable routing grommets
Yes
-
Tool-less push-to-lock
Both side panels
-
Captive thumbscrews
HDD brackets, SSD brackets, Top panel, Bottom fan bracket
-
Left side panel
Steel or Tempered glass (RGB version: Tempered glass only)
-
Right side panel
Steel or Tempered glass (Solid/White RGB: Steel, TG/Black RGB: Tempered Glass)
Compatibility
-
Motherboard compatibility
E-ATX / ATX / mATX / ITX / SSI-EEB / SSI-CEB
-
Power supply type
ATX
-
PSU max length
230 mm
-
GPU max length
461 mm total, 423 mm with front fan mounted
-
CPU cooler max height
188 mm
-
Front radiator
Up to 360/420 mm, including 360x180 mm
-
Rear radiator
Up to 120/140 mm
-
Bottom radiator
Up to 360/420 mm (458 mm max length)
-
Cable routing space
32 mm
Dimensions
-
Case dimensions (LxWxH)
544 x 242 x 530 mm
-
Case dimensions w/o feet/protrusions/screws
525 x 242 x 495 mm
-
Net weight
11.1 kg except for Solid (10.4 kg) and White TG (10.8 kg)
-
Package dimensions (LxWxH)
640 x 343 x 674 mm
-
Gross weight
13.7 kg except for Solid (13 kg) and White TG (13.4 kg)
