Leírás és Paraméterek
DISPLAY CHARACTERISTICS
| Design | Open Frame |
| Diagonal | 15", 38cm |
| Panel | TN LED |
| Native resolution | 1024 x 768 (0.8 megapixel) |
| Aspect ratio | 4:3 |
| Panel brightness | 370 cd/m² |
| Brightness | 330 cd/m² with touch |
| Light transmittance | 90% |
| Static contrast | 700:1 |
| Response time (BTB) | 8ms |
| Viewing zone | horizontal/vertical: 170°/160°, right/left: 85°/85°, up/down: 80°/80° |
| Colour support | 16.2mln (6bit + Hi-FRC) |
| Horizontal Sync | 31.4 - 60kHz |
| Viewable area W x H | 304 x 228mm |
| Pixel pitch | 0.297mm |
| Bezel colour and finish | black, matte |
TOUCH
| Touch technology | projective capacitive |
| Touch points | 10 (HID, only with supported OS) |
| Touch method | stylus, finger, glove (latex) |
| Touch interface | USB |
| Supported operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Through-Glass | 6mm |
| Palm rejection | yes |
INTERFACES / CONNECTORS / CONTROLS
| Analog signal input | VGA x1 |
| Digital signal input | HDMI x1 DisplayPort x1 |
| HDCP | yes |
FEATURES
| Extra | anti-fingerprint coating, touch through-glass |
| Glass hardness | 7H |
| Water and dust protection | IP65 (front) |
| OSD key lock | yes |
GENERAL
| OSD languages | EN, DE, FR, ES, IT, CN, JP |
| Control buttons | Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power |
| User controls | picture (contrast, brightness, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (time out, position, H-position, V-position, Touch switch), option (reset, language, source select, display mode, factory) |
| Plug&Play | DDC2B |
MECHANICAL
| Orientation | landscape, portrait, face-up |
| VESA mounting | 100 x 100mm |
ACCESSORIES INCLUDED
| Cables | power, USB, HDMI, DP |
| Guides | quick start guide, safety guide |
| Other | AC adapter |
| Cable cover | yes |
POWER MANAGEMENT
| Power supply unit | external |
| Power supply | DC DC 12 V |
| Power usage | 9W typical, 1.5W stand by, 0.3W off mode |
SUSTAINABILITY
| Regulations | CE, EAC, RoHS support, ErP, WEEE, cULus, REACH |
| Energy efficiency class (Regulation (EU) 2017/1369) | E |
| REACH SVHC | above 0.1%: Lead |
DIMENSIONS / WEIGHT
| Product dimensions W x H x D | 337.5 x 265.5 x 44.5mm |
| Box dimensions W x H x D | 435 x 335 x 165mm |
| Pallet volume | 78pcs |
| Pallet dimensions W x H x D | 910 x 1140 x 1987mm |
| Weight (without box) | 2.7kg |
| Weight (with box) | 4kg |
| EAN code | 4948570118380 |
COMPATIBLE ACCESSORIES
| Mounts/stands/brackets | OMK1-1 |
RELATED INFORMATION
| Product series | ProLite TF1634MC-B7X, ProLite TF1734MC-B7X, ProLite TF2234MC-B7X, ProLite TF1934MC-B7X |
| Related products | RC TOUCHV01, OMK1-1 |
