Leírás és Paraméterek
| Form Factor | M.2, 22mm x 80mm (2280) |
| Interface | PCIe NVMe Gen3 x4 |
| Capacities1 | 240GB, 480GB |
| NAND | 3D TLC |
| Self-Encrypting Drive (SED) | AES 256-bit Encryption |
| Sequential Read/Write | 240GB – 2,200MBs/290MBs 480GB – 3,200MBs/565MBs |
| Steady-State 4k Read/Write2 | 240GB – 111,000/12,000 IOPS 480GB – 205,000/20,000 IOPS |
| Total Bytes Written (TBW)3 | 240GB – 248TBW 480GB – 475TBW |
| Latency Read (Avg) | 161µs |
| Latency Write (Avg) | 75µs |
| Power Loss Protection (Power Caps) | Yes |
| Enterprise SMART tools | Reliability tracking, usage statistics, SSD life remaining, wear leveling, temperature |
| Endurance | 240GB — (0.5 DWPD/5yrs)3 480GB — (0.5 DWPD/5yrs)3 |
| Power Consumption | 240GB: Idle: 1.82W Average Read: 1.71W Average Write: 3.16W Max Read: 1.81W Max Write: 3.56W 480GB: Idle: 1.90W Average Read: 1.74W Average Write: 4.88W Max Read: 1.81W Max Write: 5.47W |
| Storage temperature | -40°C ~ 85°C |
| Operating temperature | 0°C ~ 70°C |
| Dimensions | 80mm x 22mm x 3.8mm |
| Weight | 240GB – 8g 480GB – 9g |
| Vibration operating | 2.17G Peak (7–800Hz) |
| Vibration non-operating | 20G Peak (10–2000Hz) |
| MTBF | 2 million hours |
| Warranty/support4 | Limited 5-year warranty with free technical support |
