Leírás és Paraméterek
|
General |
|
|
Brand |
Mushkin Enhanced |
|
Series |
Vortex |
|
Model |
MKNSSDVT512GB-D8 |
|
Type |
M.2 (2280) Internal Solid State Drive (SSD) |
|
Used For |
Consumer |
|
UPC |
846651033642 |
|
Physical |
|
|
Form Factor |
M.2 (2280) |
|
Capacity |
512GB |
|
Interface |
PCIe Gen4 x4 NVMe 1.4 |
|
Controller |
InnoGrit IG5236 |
|
Height |
3.8mm |
|
Width |
80.0mm |
|
Depth |
22.0mm |
|
Weight |
7g |
|
Performance |
|
|
Max Sequential Read |
Up to 6750MB/s |
|
Max Sequential Write |
Up to 2635MB/s |
|
Max 4K Random Read IOPS |
Up to 200,000 |
|
Max 4K Random Write IOPS |
Up to 645,000 |
|
MTBF |
1,500,000 hours |
|
TBW |
250TB |
|
Features |
|
|
Features |
MEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected |
|
- Built-in LDPC ECC provides the most-powerful data correction level in use today |
|
|
- End-to-end data path protection |
|
|
- Global wear-leveling evens program/erase counts across data blocks to extend lifespan |
|
|
512MB DDR4 DRAM |
|
|
SLC caching accelerates burst performance |
|
|
L1.2 power mode support for ultra-low power consumption |
|
|
NVMe Security Erase support |
|
|
NVMe Deallocate function support (NVMe equivalent of TRIM command) |
|
|
High-reliability 3D NAND flash |
|
|
S.M.A.R.T. support |
|
|
User-upgradeable firmware |
|
|
Temperature sensor |
|
|
RoHS, FCC, CE |
|
|
Power Consumption (Idle): 0.1W |
|
|
Power Consumption (Active): Up to 7W |
|
|
Max sequential speeds and IOPS measured using CrystalDiskMark 8.0.1 x64. |
|
|
Environmental |
|
|
Operating Temperature |
0°C-70°C |
|
Storage Temperature |
-40°C-85°C |
|
Max Shock Resistance |
1500G |
|
Power Supply |
3.3V DC |
