Leírás és Paraméterek
- Power
-
3000 VA / 3000 W
- Type
-
On-line
- Nominal Input Voltage
-
230Vac
- Nominal Output Voltage
-
200*/208*/220/230/240 VAC
*Derated capacity to 80% when the output voltage is adjusted to 200VAC/208VAC
- Accepted Input Voltage Range
-
110-300 VAC ± 5% @ 50% load
160-300 VAC ± 5% @ 100% load
- Frequency
-
40Hz ~ 70 Hz
- Transfer time
-
AC-DC: Zero
Inverter to Bypass: 4ms
- Typical Backup Time
-
25% Load - 26 min
50% Load - 11 min
75% Load - 6 min
100% Load - 3 min
- Efficiency
-
High efficiency up to 96%
- Communication Port
-
RS232 / USB / Intelligent Port (not included in the package)
- Outlets
-
8 x IEC C13 + 1 x IEC C19
- Battery Specification
-
6 x 12V 9Ah
- Battery Compatibility
-
nJoy PW9123
- Software
-
Monitor & Control over USB, LAN and Internet (SNMP card optional)
Online download (https://www. power-software-download.com/viewpower.html)
- Features
-
Pure sine wave output
True Double Conversion
Auto-Restart while AC is recovering
External battery pack (optional)
High efficiency up to 96%
User-friendly and easy-shift
LCD Output
Power Factor 1.0
EPO function
Software management
Rack/Tower design
- LCD Display
-
UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions
- Environment
-
Humidity: 0-90 % (nin-condensing)
Temperature: 0-40 grades Celsius
Noise level: less than 50 dB
- Physical Dimensions
-
Dimensions: 630 x 438 x 88 mm
Weight: 27.5 kg
