Leírás és Paraméterek
| HARDWARE FEATURES | |
|---|---|
| Interface | 1x 1Gbps Ethernet Port |
| Button | Reset |
| Power Supply | 802.3at PoE/ 48V Passive PoE |
| Power Consumption | EU: 12.5W(802.3at PoE or Passive PoE) US: 14.7W(802.3at PoE or Passive PoE) |
| Dimensions ( W x D x H ) | 11.1 x 7.2 x 2.2 in (280.4 x 182.2 x 56.9 mm)*** |
| Antenna Type | 2 Detachable External Dual-Band Antennas • 2.4 GHz: 3 dBi • 5 GHz: 5 dBi |
| Bluetooth | V5.2 |
| Mounting | Pole / Wall mounting (Kits included) |
| WIRELESS FEATURES | |
|---|---|
| Wireless Client Capacity | 1,000+§ |
| Concurrent Clients | 1,020+§ |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | • 2.4 GHz • 5 GHz |
| Signal Rate | • 5 GHz: 1201 Mbps • 2.4 GHz: 574 Mbps |
| Wireless Functions | • Multiple SSIDs (16 SSIDs, 8 for each band) • Enable/Disable Wireless Radio • Enable/Disable SSID Broadcast • Guest Network • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS(WMM) • Seamless Roaming‡ • Mesh? • Beamforming‡ • MU-MIMO‡ • OFDMA‡ • Rate Limit(Based on SSID/Client) • Load Balance • Airtime Fairness • Band Steering • RADIUS Accounting • MAC Authentication • Reboot Schedule • Wireless Schedule • Wireless Statistics • Static IP/Dynamic IP |
| Wireless Security | • Captive Portal Authentication? • Access Control • Maximum number of MAC Filter: 4,000 • Wireless Isolation Between Clients • SSID VLAN • WIDS/WIPS? • Rogue AP Detection • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power | • CE: <20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz Band1&2, EIRP) <30 dBm(5 GHz Band3, EIRP) • FCC: <25 dBm (2.4 GHz) <25 dBm (5 GHz) |
| MANAGEMENT | |
|---|---|
| Omada App | Yes |
| Restore & Backup | Yes |
| Firmware update via Web | Yes |
| NTP | Yes |
| Centralized Management | • Omada Pro Software Controller • Omada Pro Cloud-Based Controller |
| Cloud Access | Yes. Require the use of Omada Pro Cloud-Based Controller, or Omada Pro Software Controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| SSH | Yes |
| Web-based Management | Yes |
| Zero-Touch Provisioning | Yes |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Environment | • Operating Temperature: -30 °C–70 °C (-22 °F–158 °F); • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F); • Operating Humidity: 10%–90% non-condensing; • Storage Humidity: 5%–90% non-condensing; |
