Leírás és Paraméterek
Standard
- Compliant with HomePlug AV2
- IEEE 1901 and HomePlug AV standard
Powerline Data Rate
- Transmit: up to 1800 Mbps*
- Receive: up to 1800 Mbps*
Access Methods
- CSMA/CA channel-access schemes
HomePlug Modulation
- OFDM symbol modulation
- QAM 4096/1024/256/64/16
- QPSK, BPSK, ROBO carrier modulation schemes
Range
- Max. range up to 300 meters over power line
Security
- 128-bit AES encryption
Quality of Service (QoS)
- Supports up to 4-level type QoS
Frequency Band
- 2 MHz to 86 MHz
IGMP
- IGMP v1/v2/v3
System Requirements
- Operating system independent:
- Ethernet: RJ-45
- Utility software OS support:
- Microsoft Windows XP/Vista/7/8
Hardware Specifications
- Ethernet interface: Two 10/100/1000 Mbps RJ-45 connectors with auto MDI/MDIX support
- LED indicators:
- Powerline network quality:
- Green: Best
- Amber: Better
- Red: Good
- Ethernet link/activity
- Powerline network quality:
- Button:
- Encrypt/Reset button
- Power rating: 100 to 240 V AC, 50/60 Hz
- Power consumption:
- Full operation: 6 watt max.
- Socket/Connector:
- EU:
- Type F (CEE 7/4)/Type F (CEE 7/4)
- Max power rating: 16 A 250 V ~
- DE, NL, ES, PT, AT, SE, FI, NO, GR, HU, LU
- EU:
