Features
Throughput	20 Gbps
Non-Blocking	Yes
PoE enabled ports	8
PoE power budget units (watts)	100
10/100/1000 ports	8
Uplink ports	2 SFP
Serial console	Yes
USB	Yes (to future implementation)
OOB ports
Rack mount kit	Optional
Internal fans	Fanless
Maximum routes (Static)	64
Dynamic routing	512
LACP/trunking	8 LAGs/8 links per 9216
QoS priority queues	8
Maximum IGMP multicast groups	256
Max PVRST	32
Cambium Auto Edge	Yes
MTBF (hours)	338,917.20
Power budget	1000W
Power supply	AC/Internal
Weight	1.99 kg (4.375 lb)
Dimensions	21 x 4.4 x 25 cm (8.26 x 1.75 x 9.85 in)
LEDs per port	Link/activity Poe
Rack mountable	Yes 1U
Temperature ranges	-0°C to +50°C (+32°F to +122°F)
Operating humidity	+55° at 95% RH
Storage temperature	-40°C to +70°C (-40°F to +158°F)
cnMatrix All Models
Quality of Service	ACL mapping and marking of ToS/DSCP (COS) ACL mapping to priority queue Honoring DSCP and 802.1p(CoS) Priority queue management using Weighted Round Robin (WRR), Strict Priority (SP) and a combination of WRR and SP ACL mapping marking of 802.1p DiffServ support Traffic shaping/metering
Traffic Management	ACL-based inbound rate limiting policies Inbound rate limiting per port Broadcast, multicast and unknown unicast rate limiting Outbound rate limiting per port/queue
Security	802.1x authentication DHCP snooping Neighbor Discovery (ND) inspection Radius/Tacacs/Tacacs+ Secure shell MAC authentication RADIUS authentication/authorization Authentication, Authorization, and Accounting (AAA) Secure copy (SCP) Local username/password
Management	cnMaestro (cloud management) DHCP autoconfiguration Embedded DHCP server Industry standard Command Line Interface (CLI) Embedded web management (HTTP/HTTPS) Out of band Ethernet management client/server SSH /SSH v2 SNMP v1v2 System Network Time Protocol (SNTP) Auto Edge / Auto Attach Display log messages multiple terminals Telnet client/server
Layer 2 Feature Set	802.1s multiple spanning tree VLAN, Port, Protocol, 802.1q Auto MDI/MDIX IGMP Snooping V1v2 Per VLAN STP (PVST/PVRST) IGMP Proxy Flow Control per port/per queue Broadcast/Multicast/Unlearned Unicast (Storm Control) Ping/TraceRoute/ICMPv6 Bpdu guard, Root Gard LLDP/LLDP Med Port Mirroring: port based, ACL based, VLAN based Link Aggregation Groups (Static/LACP) Jumbo frame support BPDU filtering DoS Protection (Port, CPU)
