Leírás és Paraméterek
-
3.5"/2.5" Universal drive brackets
6 included, 14 positions total
-
Dedicated 2.5" drive brackets
2 trays included, 4 positions total
-
5.25” drive mounts
1
-
Expansion slots
7 + 2
-
Front ports
1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button
-
Total fan mounts
9 x 120/140 mm
-
Front fan
3 x 120/140 mm (2 x Dynamic X2 GP-14 included)
-
Top fan
3 x 120/140 mm
-
Rear fan
1 x 120/140 mm (1 x Dynamic X2 GP-14 included)
-
Bottom fan
2 x 120/140 mm
-
Dust filters
Top, 2 x front, full length bottom
-
Fixed velcro straps
Yes
-
Cable routing grommets
Yes
-
Captive thumbscrews
HDD brackets, SSD brackets, PSU bracket
-
Left side panel
Industrial sound-damped steel or Tempered Glass
-
Right side panel
Industrial sound-damped steel
Compatibility
-
Motherboard compatibility
E-ATX (max 285 mm) / ATX / mATX / mITX
-
Power supply type
ATX
-
PSU max length
250 mm (with HDD cage installed)
-
GPU max length
Storage layout: 290 mm - Open layout: 470 mm (445 mm w/ front fan)
-
CPU cooler max height
185 mm
-
Front radiator
Up to 360/280 mm
-
Top radiator
Up to 360/420 mm
-
Rear radiator
120 mm
-
Bottom radiator
Up to 240/280 mm
-
Cable routing space
30 mm
-
Vertical GPU Support (with Flex B-20 or Flex VRC-25)
65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling
Dimensions
-
Case dimensions (LxWxH)
547 x 240 x 475 mm
-
Case dimensions w/o feet/protrusions/screws
533 x 240 x 451 mm
-
Package dimensions (LxWxH)
558 x 363 x 641 mm
-
Net weight
Solid Version: 13.49 kg, TG Version: 13.45 kg
-
Package weight
Solid Version: 15.98 kg TG Version: 15.94 kg
-
Volume
57.7 liters
