Leírás és Paraméterek
-
3.5"/2.5" Universal drive mounts
2 (included)
-
Dedicated 2.5" drive mounts
4 (2 included)
-
Expansion slots
7
-
Front interface
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button
-
Total fan mounts
7x 120 or 4x 140 mm and 2x 120 mm
-
Front fan
3x 120 or 2x 140 mm, (2x Dynamic X2 GP-14 included)
-
Top fan
2x 120/140 mm
-
Rear fan
1x 120 mm, (1x Dynamic X2 GP-12 included)
-
Bottom fan
1x 120 mm (requires removal of HDD cage)
-
Dust filters
Top, front and bottom
-
Fixed velcro straps
Yes
-
Cable routing grommets
Yes
-
Captive thumbscrews
HDD, SSD and PSU brackets
-
Left side panel
Steel
-
Right side panel
Steel
Compatibility
-
Motherboard compatibility
ATX / mATX / Mini-ITX
-
Power supply type
ATX
-
PSU max length
200 mm (165 mm with HDD cage and front fan)
-
GPU max length
341 mm (360 mm without front fan)
-
CPU cooler max height
169 mm
-
Front radiator
Up to 360/280 mm
-
Top radiator
Up to 240 mm
-
Rear radiator
120 mm
-
Bottom radiator
120 mm (requires removal of HDD cage)
-
Cable routing space
17-28 mm
-
Radiator Support – Additional Details
Maximum radiator width: 145mm for front mounting. Maximum motherboard component height for top mounted radiator: 40 mm. For more details, consult the manual.
Dimensions
-
Case dimensions (LxWxH)
424 x 210 x 475 mm
-
Case dimensions w/o feet/protrusions/screws
412 x 210 x 455 mm
-
Package dimensions (LxWxH)
542 x 320 x 554 mm
-
Net weight
Solid: 7.7 kg TG: 8.1 kg
-
Gross weight
Solid: 9.3 kg TG: 9.8 kg
-
Volume
39.4 Liters
