Leírás és Paraméterek
-
3.5"/2.5" Universal drive mounts
6 included, 14 positions total + 1 Multibracket
-
Dedicated 2.5" drive mounts
2 included, 4 positions total
-
Expansion slots
7 + 2
-
Front interface
1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button
-
Total fan mounts
9x 120/140 mm
-
Front fan
3x 120/140 mm (2x Dynamic X2 GP-14 included)
-
Top fan
3x 120/140 mm
-
Rear fan
1x 120/140 mm (1x Dynamic X2 GP-14 included)
-
Bottom fan
2x 120/140 mm
-
Dust filters
Top, front and bottom
-
Fixed velcro straps
Yes
-
Cable routing grommets
Yes
-
Captive thumbscrews
HDD, SSD and PSU brackets
-
Left side panel
Steel
-
Right side panel
Steel
Compatibility
-
Motherboard compatibility
E-ATX (max 285 mm)/ ATX / mATX / Mini-ITX
-
Power supply type
ATX
-
PSU max length
250 mm (with HDD cage installed)
-
GPU max length
Open layout: 470 mm (445 mm w/ front fan) - Storage layout: 290 mm
-
CPU cooler max height
185 mm
-
Front radiator
Up to 360/280 mm
-
Top radiator
Up to 360/420 mm
-
Rear radiator
120 mm
-
Bottom radiator
Up to 240/280 mm
-
Cable routing space
30 mm
Dimensions
-
Case dimensions (LxWxH)
542 x 240 x 474 mm
-
Case dimensions w/o feet/protrusions/screws
541 x 240 x 454 mm
-
Package dimensions (LxWxH)
634 x 542 x 324 mm
-
Net weight
Solid: 10.1 kg TG: 10.5 kg
-
Gross weight
Solid: 12.8 kg TG: 13.2 kg
-
Volume
58.95 liters
