Leírás és Paraméterek
-
	ModelGP-AP750GM
-
	TypeIntel Form Factor ATX 12V v2.31
-
	PFCActive PFC (>0.9 typical)
-
	Input Voltage100-240 Vac (full range)
-
	Input Current10A
-
	Input Frequency47-63 Hz
-
	Output Capacity750W
-
	Dimension150 x 160 x 86mm
-
	Fan Type135mm Double ball bearing fan
-
	80 PLUSGold
-
	Efficiency90% at typical load
-
	MTBF>100,000 hours
-
	ProtectionOVP/OPP/SCP/UVP/OCP/OTP
-
	Power Good Signal100ms ~ 150ms
-
	Hold Up Time> 16m sec at full load (115V)
-
	Cable TypeFlat, All black
-
	ConnectorsATX/MB 20+4 Pin x 1 : 650mm
 CPU/EPS 4+4 Pin x 2 : 800mm*1 , 650mm*1
 PCI-e 6+2 Pin x 4 : 750mm*2 , 650mm+150mm*1
 SATA x6 + 4 Pin Peripheral x2 :
 550mm+100mm+100mm+100mm*1
 450mm+100mm+100mm+100mm *1
 4 Pin Peripheral x 3 + 4 pin Floppy x 1 : 450mm+100mm+100mm+100mm*1
 4 Pin Floppy x 1 : 100mm
