DISPLAY CHARACTERISTICS
| Design | Edge to edge glass |
| Diagonal | 17", 43cm |
| Panel | TN LED |
| Native resolution | 1280 x 1024 (1.3 megapixel) |
| Aspect ratio | 5:4 |
| Panel brightness | 250 cd/m² |
| Brightness | 215 cd/m² with touch |
| Light transmittance | 85% |
| Static contrast | 1000:1 |
| Response time (GTG) | 5ms |
| Viewing zone | horizontal/vertical: 170°/160°, right/left: 85°/85°, up/down: 80°/80° |
| Colour support | 16.7mln |
| Horizontal Sync | 31.4 - 80kHz |
| Viewable area W x H | 338 x 270.5mm, 12 x 9" |
| Pixel pitch | 0.264mm |
| Bezel colour and finish | black, matte |
TOUCH
| Touch technology | projective capacitive |
| Touch points | 10 (HID, only with supported OS) |
| Touch method | stylus, finger, glove (latex) |
| Touch interface | USB |
| Supported operating systems | All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
INTERFACES / CONNECTORS / CONTROLS
| Analog signal input | VGA x1 |
| Digital signal input | DVI x1 |
| Audio output | Speakers 2 x 2W |
FEATURES
| Glass thickness | 1.5mm |
| Water and dust protection | IPX3 (front) |
| OSD key lock | yes |
GENERAL
| OSD languages | EN, DE, FR, ES, IT, CN, JP |
| Control buttons | Menu, Up/Left/ Auto adjustment button, Down/Right button, Return/Exit button, Power |
| User controls | picture (backlight, brightness, contrast, sharpness) display (auto adjustment, H position, V position, pixel clock, phase) colour (colour temp, picture mode) input, audio (volume, mute) other (reset, OSD time, OSD H position, OSD V position, language) information |
| Plug&Play | DDC2B |
MECHANICAL
| Tilt angle | 70° up; 10° down |
| VESA mounting | 100 x 100mm |
| Cable management system | yes |
ACCESSORIES INCLUDED
| Cables | power, VGA, DVI, USB, Audio |
| Guides | quick start guide, safety guide |
| Other | AC adapter, mylar sheet (for VESA mount) |
POWER MANAGEMENT
| Power supply unit | external |
| Power supply | DC 12 V |
| Power usage | 20W typical, 3W stand by, 3W off mode |
SUSTAINABILITY
| Regulations | CE, TÜV-Bauart, RoHS support, ErP, WEEE, cULus, REACH |
| Energy efficiency class (Regulation (EU) 2017/1369) | F |
| REACH SVHC | above 0.1%: Lead |
DIMENSIONS / WEIGHT
| Product dimensions W x H x D | 392.5 x 364 x 198mm |
| Weight (without box) | 4.4kg |
| EAN code | 4948570114887 |
