Leírás és Paraméterek
| BAR 300 |
| Spec |
|
General Specifications
|
|
| Power supply
|
100 - 240V AC, ~ 50/60Hz
|
| Networked standby power
|
< 2.0 W
|
| Operating temperature
|
0°C - 45 °C
|
|
Audio Specifications
|
|
| Total speaker power output (Max @THD 1%)
|
260W
|
| Soundbar transducer
|
4x (46x90)mm racetrack drivers, 2x 0.75" (20mm) tweeters
|
| Frequency response
|
50Hz - 20kHz (-6dB)
|
| Audio inputs |
1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)
|
|
Dimensions
|
|
| Soundbar dimensions (W x H x D)
|
820 x 56 x 103.5 mm / 32.3’’ x 2.2’’ x 4.1’’
|
| Soundbar weight
|
2.5kg/5.5 lbs
|
| Packaging dimensions (W x H x D)
|
1060 x 120 x 170 mm/ 41.7" x 4.7" x 6.7"
|
| Packaging Weight
|
4.1 kg / 9 lbs
|
|
Control and Connection Specifications
|
|
| USB port
|
Type A
|
| USB rating
|
5V DC, 0.5A
|
| Supporting file format
|
MP3
|
| MP3 codec
|
MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
|
| MP3 sampling rate
|
16 - 48 kHz
|
| MP3 bitrate
|
80 - 320 kpbs
|
| Bluetooth version
|
5.0
|
| Bluetooth profile
|
A2DP 1.2, AVRCP 1.5
|
| Bluetooth transmitter frequency range
|
2400 MHz – 2483.5 MHz
|
| Bluetooth transmitter power
|
<15 dBm (EIRP)
|
| Wi-Fi network
|
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
|
| 2.4G Wi-Fi transmitter frequency range |
2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
|
| 2.4G Wi-Fi transmitter power
|
< 20 dBm (EIRP)
|
| 5G Wi-Fi transmitter frequency range
|
5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz
|
| 5G Wi-Fi transmitter power |
5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)
|
| Video Specifications | |
|
HDMI video input
|
1
|
| HDMI video output (with Enhanced Audio Return Channel, eARC)
|
1
|
| HDMI HDCP version
|
2.3
|
| HDR pass through
|
HDR10, Dolby Vision
|
