| 75UR640S3ZD |
| UHD TV Signage |
| |
| |
|
|
| |
| All Spec |
| |
| DESIGN |
| |
- Stand Type: 2 Pole
-
front color: Ashed Blue
.
|
| |
| |
| DISPLAY |
| |
- Inch: 75”
-
Resolution: 3840 X 2160 (UHD)
-
Static (Panel) Contrast Ratio: 1200:1
.
|
| |
| |
| VIDEO |
| |
- HDR_HDR 10 Pro: Yes
-
HDR_HLG: Yes
.
|
| |
| |
| AUDIO |
| |
- Speaker (sound output): 10W + 10W
-
Speaker System: 2.0 ch
-
LG Sound Sync: Yes (Required Bluetooth)
.
|
| |
| |
| BROADCASTING SYSTEM |
| |
- Digital (Terrestrial,Cable,Satellite): DVB-T2/C/S2
-
Analog (NTSC / SECAM / PAL): PAL/SECAM
-
Global IPTV Support: Yes
.
|
| |
| |
| SMART FUNCTION |
| |
- Commercial Smart UX: webOS version (webOS 6.0), Smart Home (Launcher Bar), Web Browser, Pre-loaded App (YouTube only, Jun~), SDP Server compatibility, Mood Display
-
Connectivity: Soft AP, WiFi (Version) (802. 11ac), Screen Share (Miracast), Smart Share, Bluetooth Audio Playback, HDMI-ARC (ARC, HDMI2)
.
|
| |
| |
| OTHER FEATURE |
| |
- Ease Installation: USB Cloning
-
Management: SI Compatible Protocol (TVLink Tuner), IR Out (RS-232C , HDMI)
-
Hospitality Feature: Hotel Mode / PDM / Installer Menu, One Channel Map, IP Channel Manager, External Speaker Out (Int Variable/Fixed, 3.5mm, Stereo, Single ended Type(GND,L+,R+), 2W+2W with 8 ohm)
-
USB: Moving Picture Playback (SD/HD/Plus HD)
-
Setting Option: Motion Eye Care
.
|
| |
| |
| VERTICAL FUNCTION |
| |
- Signage (Corporate/Retail): Vertical Setup, Fail Over, Play Via URL, NTP Server Setting, CISCO Certi. Compatibility (TBD (July~))
-
Set Side: HDMI In (3 (2.0)), Headphone Out (Phone Jack Type), RS-232C(D-Sub 9pin / Phone jack) (Phone Jack, 4pin), LG SVC only (Phone jack type) (Phone Jack Type), CI Slot (CI+ 1.4 ECP)
-
Set Rear / Bottom: USB (2.0), RF In (2), Digital Audio Out (Optical), External Speaker Out(3.5mm phone jack), RJ45 (Usage Purpose) (LAN)
.
|
| |
| |
| ETC |
| |
- VESA Compatible: 300x300
-
Anti-theft System: Kensington Lock
.
|
| |
| |
| MECHANIC |
| |
- Weight without Stand: 31.4
-
Weight with Stand: 32.1
-
Weight in Shipping: 41.5
-
Size without Stand: 1678 x 964 x 59.9
-
Size with Stand: 1678 x 1027 x 362
.
|
| |
| |
| POWER |
| |
- Power Supply (Voltage, Hz): AC 120 V~, 50 / 60 Hz
-
Power Consumption(Max.): 228W
-
Power Consumption(Typ.): 202W
-
Standby Power Consumption: Under 0.5W
.
|
| |
| |
| REQUIRED LISTING(CERTIFICATION) |
| |
- Safety: CB, CU TR
-
EMC: CE
.
|
| |
| |
| ACCESSORY |
| |
- Remote type: S-con
-
Chromecast Dongle Anti-theft Cover: Yes (option)
-
Power Cable: Attached(2m)
.
|
| |
