Leírás és Paraméterek
- Power
-
20KVA / 20KW
- Type
-
On-line
- Technology
-
Three phase in / three phase out
- Nominal Input Voltage
-
3 x 400 VAC (3Ph+N)
- Nominal Output Voltage
-
3 x 360*/380/400/415 VAC (3Ph+N)
- Accepted Input Voltage Range
-
190-520 VAC (3-phase) @ 50% load
305-478 VAC (3-phase) @ 100% load
- Frequency
-
46 ~ 54Hz
- Outlets
-
Terminal Block Wiring
- Transfer Time to Battery / AC
-
Zero
- Typical Backup Time
-
Depending on the number of batteries
- Communication Port
-
RS232 / USB / EPO / SNMP / Modbus / AS400 (cards optional)
- Battery Type
-
Sealed and leak proof maintenance
- Battery Specification
-
Internal (not included): 32~40 pieces of 12V lead acid 7Ah or 9Ah
External (optional): 12V lead acid, (N + N) pcs x 1 string; N=16~20
- Software
-
ViewPower Network Edition and VMWare Shutdown Wizard
- Features
-
On-line with double conversion
Smart battery charger to optimize batteries performance
Adjustable batteries design
Output power factor 1.0
Optional isolation transformer
DSP technology guarantees high performance
Active power factor correction in all phases
High Efficiency on AC mode up to 95.5%
EPO function
Maintenance bypass
4.3” large touch LCD display
Power management over SNMP / Modbus / AS 400 card
ECO mode operation for energy saving
Dual Input for generator compatibility
- LCD Display
-
UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions
- Efficiency
-
AC Mode ≥ 95.5 % with fully charged batteries
Battery Mode ≥ 94.5 % with fully charged batteries
ECO Mode ≥ 98.5 % with fully charged batteries
- Environment
-
< 95 % RH at 0-40ºC (non-condensing)
Noise Level: Less that 60dB at 1 m
- Physical Dimensions
-
Dimensions: 630 x 250 x 750 mm
Weight: 44.5
- Compatibility
-
With external battery pack (please refer to the Support section)
