Product specs
EAN6422956012328
PNUP33TOP130KRAAZ01B
Phase3 Phase In - 3 Phase Out
TechnologyOn-line (VFI)
TypologyTower
Output waveformPure Sine Wave
Output Power Factor1.0
Power30KVA / 30KW
Input Nominal Voltage3x 400V (3Ph+N)
Input Voltage Range
110-300 VAC @ 50% load
176-276 VAC @ 100% load
Input Nominal Frequency
40 ~ 70Hz
Output Nominal Voltage
3 x 360*/380/400/415 VAC (3Ph+N)
Output Voltage Precision
± 1%
Batteries PresenceInternal and / or External
Batteries Installed
No batteries installed
Up to 80 pcs of 12V9Ah or 12V7Ah type batteries supported
Outlets
Terminal Block Wiring
LCD DisplayYes (touch screen)
Communication PortsRS232USBSNMPEPO
Efficiency
up to 98.5 %*
Noise Level<65dB
Parallel operationup to 4 units
Features
Smart battery charger to optimize batteries’ performance
Adjustable batteries design
Optional isolation transformer*
DSP technology guarantees high performance
Active power factor correction in all phases
Maintenance bypass
5” large touch LCD display
Power management over SNMP / Modbus / AS 400 card
ECO mode operation for energy saving
Generator CompatibleYes
Dimensions (L x W x H)
785 x 300 x 1000 mm
Weight
88 Kgs
Remarks
*For detailed specs please check product datasheet
