Leírás és Paraméterek
Product specs
EAN6422956012342
PNUP33TOP160KRAAZ01B
Phase3 Phase In - 3 Phase Out
TechnologyOn-line (VFI)
TypologyTower
Output waveformPure Sine Wave
Output Power Factor1.0
Power60KVA / 60KW
Input Nominal Voltage3x 400V (3Ph+N)
Input Voltage Range
110-300 VAC @ 50% load
176-276 VAC @ 100% load
Input Nominal Frequency
40 ~ 70Hz
Output Nominal Voltage
3 x 360*/380/400/415 VAC (3Ph+N)
Output Voltage Precision
± 1%
Batteries PresenceExternal Only
Batteries Installed
No batteries installed
Outlets
Terminal Block Wiring
LCD DisplayYes (touch screen)
Communication PortsRS232USBSNMPEPO
Efficiency
up to 98.5%*
Noise Level<65dB
Parallel operationup to 4 units
Features
Smart battery charger to optimize batteries’ performance
Adjustable batteries design
Optional isolation transformer*
DSP technology guarantees high performance
Active power factor correction in all phases
Maintenance bypass
5” large touch LCD display
Power management over SNMP / Modbus / AS 400 card
ECO mode operation for energy saving
Generator CompatibleYes
Dimensions (L x W x H)
785 x 300 x 1000 mm
Weight
91 Kgs
Remarks
*For detailed specs please check product datasheet
