Product specs
EAN6422956013004
PNUPCMTOP960HASCG01B
PhaseSingle Phase
TechnologyOn-line (VFI)
TypologyTower
Output waveformPure Sine Wave
Output Power Factor0.9
Power6KVA / 5.4KW
Input Nominal Voltage208 / 220 / 230 / 240V
Input Voltage Range
80-300 VAC
Input Nominal Frequency
50 Hz/60 Hz
Output Nominal Voltage
208/220/230/240 VAC
Output Voltage Precision
± 1% (Battery mode)
Batteries Installed
No batteries installed
16 pieces of 12V lead acid 7Ah or 9Ah
Batteries PresenceInternal Only
Typical Backup Time
Depending on the batteries installed and load
Outlets
Terminal Block Wiring
Efficiency
≥ 96% in ECO Mode at full charged battery
LCD DisplayYes
Communication PortsUSBHID USBSNMPEPO
Parallel operationNot Supported
Generator CompatibleYes
Noise Level<55dB
Features
On-line UPS
HID USB communication
Auto Restart
Auto Recharge
Cold start
Internal bypass
EPO function
Multifunctional color LCD
Generator compatible
ECO Mode for energy saving
Software management
Dimensions (L x W x H)
196 x 702 x 412 mm
Weight
54 kg
Remarks
*For detailed specs please check product datasheet
