Leírás és Paraméterek
| Management Type | Web Managed |
| CPU | Intel Celeron ® J4125 quad-core 2.0 GHz processor (burst up to 2.7 GHz) |
| CPU Architecture | 64-bit x86 |
| System Memory | 8 GB (2 x 4 GB) |
| Drive Bays | 4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Number of Ports | 16 |
| 1GbE (RJ45) | 14 |
| 1GbE SFP/RJ45 Combo Ports | 2 |
| Total PoE Ports | 16 |
| PoE PSE (802.3af, 15.4W) | Ports 1-16 |
| PoE+ PSE (802.3at, 30W) | Ports 1-16 |
| PoE Power Output | Ports 1-16 (Max 30W) |
| Total PoE Power Budget | 140W |
| USB 3.2 Gen 1 port | 3 |
| Management Port | 2 x 2.5GbE |
| HDMI Output | 2 |
| Power Supply Description | Internal Power Supply Unit |
| Max. Power Consumption | 250W |
| Input Power Type | AC |
| Input Voltage Range | 100-240VAC, 50/60 Hz |
| MAC Address Table | 8K |
| Total Non-Blocking Throughput | 16Gbps |
| Switching Capacity | 32Gbps |
| Management Interface | Web |
| Energy Efficient Ethernet (IEEE 802.3az complaint) | Yes |
| Fan | System: 12 x 12 cm (12V DC) |
| Supported Standards | IEEE 802.3u 100Tx Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3z 1000Base-X IEEE 802.3x Full-duplex flow control IEEE 802.3af/at Power-over-Ethernet (PoE) IEEE 802.1q Virtual LANs (VLAN) IEEE 802.1p QoS Protocol for Traffic Prioritization IEEE 802.3az Energy Efficient Ethernet IEEE 802.3af/at Power-over-Ethernet (PoE) |
| Form Factor | Desktop |
| LED Indicators | Per Port: Link/Activity/Speed/PoE Per System: Warning/PoE/Fan |
| LCD Management | Yes |
| Buttons | Device PSU power button Host power button Host reset button(load default) Switch reset button |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Relative Humidity | 5% to 95% non-condensing, wet bulb: 27°C (80.6°F) |
| Certifications | CE, FCC, VCCI, BSMI |
| Electromagnetic Compliance | CLASS A |
| Jumbo Frames | Yes |
| QTS Built-in | Yes |
| Internal Network Bandwidth | 2 x 1GbE |
| Graphics Processors |
