Connector(s)
External Ports
4 - USB 3.2 Type-A (9 pin, Gen 1, 5Gbps)
1 - USB Micro-B (5 pin) (Power)
Host Connectors
1 - USB 3.2 Type-A (9 pin, Gen 1, 5Gbps)
Environmental
Operating Temperature
0°C to 70°C (32°F to 158°F)
Storage Temperature
-40°C to 80°C (-40°F to 176°F)
Humidity
0% ~ 85% RH (no condensation)
Hardware
USB-C Device Port(s)
No
USB-C Host Connection
No
Fast-Charge Port(s)
No
Ports
4
Interface
USB 3.2 Gen 1 (5Gbps)
Bus Type
USB 3.2 Gen 1 (5Gbps)
Industry Standards
USB 3.2 Gen 1 - Backward compatible with USB 2.0 and 1.1
Chipset ID
VIA - VL817
Packaging Information
Shipping (Package) Weight
4.7 oz [133.0 g]
Package Height
1.2 in [3.0 cm]
Package Length
6.7 in [17.0 cm]
Package Width
5.6 in [14.2 cm]
Package Quantity
1
Performance
Maximum Data Transfer Rate
5 Gbps (USB 3.2 Gen 1)
Type and Rate
USB 3.2 Gen 1 - 5 Gbit/s
UASP Support
Yes
MTBF
107,000 hours
Physical Characteristics
Color
Space Gray
Form Factor
Compact
Product Height
0.6 in [1.6 cm]
Weight of Product
2.9 oz [82.0 g]
Product Length
16.5 in [42.0 cm]
Product Width
2.1 in [5.4 cm]
Material
Plastic
Cable Length
11.8 in [30 cm]
Power
Power Source
Bus Powered
Special Notes / Requirements
System and Cable Requirements
A host computer with an available USB-A port.
(Optional - when USB bus power is inadequate) USB Power Source with USB Micro-B host cable to provide supplemental power to the USB hub (up to 4.5W).
Note
USB 3.2 Gen 1 (5Gbps) is also known as USB 3.1 Gen 1 (5Gbps) and USB 3.0 (5Gbps).
What's in the Box
Included in Package
1 - USB Hub
