Leírás és Paraméterek
| BIZTONSÁG | |
|---|---|
| Hozzáférés-vezérlés | Source/Destination IP Based Access Control |
| Szűrés | • WEB Group Filtering*4 • URL Filtering • Web Security*4 |
| ARP-s támadás elleni védelem | • Sending GARP Packets*4 • ARP Scanning*4 • IP-MAC Binding*4 |
| Hálózati támadások elleni védelem | • TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN |
| HARDVER JELLEMZŐK | |
|---|---|
| Csatlakozások | • 1× 10G SFP+ WAN Port • 1× 10G SFP+ WAN/LAN Port • 1× Gigabit SFP WAN/LAN Port • 8× Gigabit RJ45 WAN/LAN Ports |
| Hálózati összeköttetés | • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100? STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100? STP (Max 100 m) • 1000BASE-T: UTP category 5e, 6 cable (Max 100 m) |
| Ventilátorok száma | 2 |
| Gomb | Reset Button |
| Hálózati tápegység | Redundant Dual Power Supplies (100–240 VAC, 50/60 Hz) |
| Flash | 4MB SPI NOR + 256 MB NAND |
| DRAM | 4 GB DDR4 |
| Méretek (Sz x Mé x Ma) | 17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm) |
| Védelem | 4 kV surge protection |
| Burkolat | Steel |
| Felszerelés | Rack Mountable |
| Max. áramfelvétel | • 26.36W (with USB3.0 connected) • 19.12W (without USB3.0 connected) |
| MŰKÖDÉSI JELLEMZŐK | |
|---|---|
| Egyidejű munkamenet | 2,300,000 |
| New Sessions /Second | 20,000 |
| NAT (Static IP) | • Upload: 9445.82 Mbps • Download: 9449.26 Mbps |
| NAT(DHCP) | • Upload: 9426.83 Mbps • Download: 9426.20 Mbps |
| NAT(PPPoE) | • Upload: 9413.96 Mbps • Download: 9102.01 Mbps |
| NAT (L2TP) | • Upload: 9064.66 Mbps • Download: 8587.57 Mbps |
| NAT (PPTP) | • Upload: 8712.11 Mbps • Download: 8505.61 Mbps |
| 64 Byte Packet Forwarding Rate | • Upload: 1080 Mbps • Download: 1030 Mbps |
| IPsec VPN Throughput | • ESP-SHA1-AES256: 3099.4 Mbps • ESP-SHA256-AES256: 2928.4 Mbps • ESP-SHA384-AES256: 2935.7 Mbps • ESP-SHA512-AES256: 2878 Mbps |
| OpenVPN | 4424.1 Mbps |
| L2TP VPN Throughput | • Unencrypted: 10497 Mbps • Encrypted: 3178.5 Mbps |
| PPTP VPN Throughput | • Unencrypted: 10497 Mbps • Encrypted: 3178 Mbps |
| SSL VPN Throughput | 4486 Mbps |
| 1,518 Byte Packet forwarding rate | • Upload: 9970 Mbps • Download: 9970 Mbps |
| ALAPFUNKCIÓK | |
|---|---|
| WAN kapcsolati típus | • Static/Dynamic IP • PPPoE • PPTP • L2TP • 6to4 Tunnel • IPv6 Pass-Through • Mobile Broadband: 4G/3G modem for backup via USB port |
| MAC klónozása | Modify WAN/LAN MAC Address*4 |
| DHCP | • DHCP Server/Client • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP |
| IPv6 | WAN Connection |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy |
| HALADÓ FUNKCIÓK | |
|---|---|
| Advanced Routing | • Static Routing • Policy Routing |
| Sávszélesség-szabályozás | • IP/Port-based Bandwidth Control • Guarantee & Limited Bandwidth |
| Load Balance | • Intelligent Load Balance • Application Optimized Routing • Link Backup (Timing*4, Failover) • Online Detection |
| NAT | • One-to-One NAT*4 • Multi-Net NAT • Virtual Server • Port Triggering*4 • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP |
| Session Limit | IP-based Session Limit |
| VPN | |
|---|---|
| SSL VPN | • SSL VPN Server • SSL VPN Client • 500 SSL VPN Tunnels |
| IPsec VPN | • 300 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, SHA1, SHA 256, SHA 384, SHA 512, AES128, AES192, AES256 Encryption Algorithm • IKE v1/v2 • MD5, SHA1 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS) |
| PPTP VPN | • PPTP VPN Server • PPTP VPN Client (32)*6 • 300 Tunnels (Shared with L2TP) • PPTP with MPPE Encryption |
| L2TP VPN | • L2TP VPN Server • L2TP VPN Client (32)*6 • 300 Tunnels (Shared with PPTP) • L2TP over IPSec |
| OpenVPN | • OpenVPN Server • OpenVPN Client (10)*6 • 110 OpenVPN Tunnels |
| HITELESÍTÉS | |
|---|---|
| Webes hitelesítés | • No Authentication • Simple Password*5 • Hotspot(Local User / Voucher*5 / SMS*5 / Radius*5) • External Radius Sever • External Portal Sever*5 |
| VEZÉRLÉS | |
|---|---|
| Omada App | Yes. Require Omada Pro Cloud-Based Controller, or Omada Pro Software Controller. |
| Centralized Management | • Omada Pro Software Controller • Omada Pro Cloud-Based Controller |
| Cloud Access | Yes. Require Omada Pro Cloud-Based Controller, or Omada Pro Software Controller. |
| Szolgáltatás | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) |
| Kezelés | • Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute)*4 • NTP Synchronize*4 • Syslog Support • Gateway Online Detection5 • Remote Packet Capture5 |
| Zero-Touch Provisioning | Yes. Require the use of Omada Pro Cloud-Based Controller. |
| Management Features | • Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration • ZTP (Zero-Touch Provisioning)*3 |
| EGYÉB JELLEMZŐK | |
|---|---|
| Tanúsítványok | CE, FCC, RoHS |
| Csomagolás tartalma | • G611 • Power Cord • Rackmount Kit • Quick Installation Guide • RJ45 Console Cord |
| Rendszerkövetelmény | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10 MAC OS, NetWare, UNIX or Linux |
| Környezet | • Operating Temperature: 0–40 ? (32–104 ?); • Storage Temperature: -40–70 ? (-40–158 ?) • Operating Humidity: 10–90% non-condensing • Storage Humidity: 5–90% non-condensing |
