Mechanical
Dimensions	210.4 x 95 x 29 mm (8.28 x 3.74 x 1.14")
Weight	600 g (1.32 lb)
Enclosure material	Polycarbonate
Hardware
Networking interface	(8) 10/1001000 MbE RJ45 ports (1) 1G SFP port
Management interface	Ethernet in-band Bluetooth BLE
Processor	Dual-core 880 MHz, MIPS1004Kc
Memory	512 MB DDR3
Onboard flash storage	512 MB NAND
Power method	External AC/DC adapter
Power supply	27VDC, 4.4A power adapter (included)
Supported voltage range	24 - 28VDC
Max. power consumption	10W (excludes PoE output)
ESD/EMP protection	Air: ± 15 kV, contact: ± 8 kV
Operating temperature	-10 to 50° C (14 to 122° F)
Operating humidity	5 to 95% non-condensing
Certifications	CE, FCC, IC
PoE
PoE interface	(8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-)
Max. Passive PoE wattage per port	30W/27VDC
Passive PoE voltage range	27VDC
LEDs
System	Status
RJ45 data ports	PoE Speed/link/activity
SFP data port	Link/activity
